Overall System

Operating Frequencies
UHF band 656.125 – 678.500 MHz (D Band) 854.900 – 864.900 MHz (F Band) 487.125 – 506.500 MHz (I Band)  606.500 – 631.000 MHz (U Band)
Number Of Channels
10 total
Frequency Stability
±0.005%, Phase Lock Loop frequency control
Modulation Mode
FM
Frequency Response
100 Hz to 15,000 Hz
Operating Range
100 m (300') typical
Operating Temperature Range
41° F (5° C) to 113° F (45° C)
Receiver

Receiving System
True Diversity
Image Rejection
55 dB nominal, 50 dB minimum
Signal-To-Noise Ratio
>100 dB at 40kHz deviation (A-weighted), maximum modulation 40 kHz
Sensitivity
20dBµV (S/N 60dB at 5 kHz deviation, IEC-weighted)
Total Harmonic Distortion
≤ 1% (at 1 kHz, ±20 kHz deviation)
Audio Output Attenuator (ATTN)
Unbalanced: 25mV (100k ohms load), 1/4" phone jack Balanced: 50mV (Attenuator; 0dB) 12.5mV (Attenuator; -12dB) at 1 kHz ± 5kHz deviation, 100k ohm load, XLRM-type
Antenna Input
BNC-type 50 Ω – Bias voltage 12V DC, 60mA each
Dimensions
210 mm x 44 mm x 162.2 mm (W x H x D)
Weight
1.0kg
Accessories Included
Two flexible UHF antennas, rack mount adapters, AC adapters
Belt Pack

RF Power Output
High: 30mW; Low: 10mW, nominal
Spurious Emissions
According to National Regulations
Battery Type
1.5V AA alkaline or rechargeable AA NiMH (not included)
Current Consumption
150 mA typical
Battery Life
Approximately 9 hours (low), 7 hours (high)
Dimensions
66 mm x 92.3 mm x 22.5 mm (W x H x D)
Net Weight
80g
